Mentor Graphics HyperLynx Vx.2.5 2019 (x64)

HyperLynx® offers a complete suite of design analysis and verification software that meets the needs of PCB engineers at any point in the board design flow. Easy to use and integrate into your flow, HyperLynx equips hardware design engineers and PCB designers to efficiently analyze, identify, resolve, and verify critical design issues, which prevents costly re-spins, reduces design cycle times, and improves product reliability. Achieve greater innovation, faster time-to-market, and decreased costs with HyperLynx.

HyperLynx Product:

HyperLynx SI:
Analyze signal integrity issues early in the design cycle and perform protocol compliance verification.

HyperLynx PI:
Accurately model power distribution networks and noise propagation mechanisms during both pre- and post-layout phases in the PCB design process.

HyperLynx DRC
Rapidly run complex electrical rules on PCBs to verify corporate- and technology-specific rules of thumb.

HyperLynx Full-Wave Solver:
HyperLynx Full-Wave Solver delivers unprecedented speed and capacity through accelerated boundary element technology while preserving the gold-standard Maxwell accuracy. Achieve greater accuracy and fewer re-spins, even on the most complex structures.

HyperLynx Fast 3D Solver:
HyperLynx Fast 3D Solver enables efficient, full package model creation with multi-processing for faster turnaround time. It is ideally suited for power integrity, low-frequency SSN/SSO, and complete-system SPICE model generation while accounting for skin effect impact on resistance and inductance.

HyperLynx Thermal:
Fast, complete, accurate 3D modeling of complex flow and thermal fields in PCB designs.

System Requirements:
Windows 7 64 SP1 (Professional,Enterprise, Ultimate)
Windows 8.1 (Professional, Enterprise)
Windows 10 (Professional, Enterprise)
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016

Memory Recommended: 2 GB or higher
Disk Space Minimum: 7.5 GB for full installation
Mouse Recommended: Three-button mouse, Minimum: Two-button mouse
Monitor Minimum: 1024 x 768, 256 color display.
